  FORCE TEN™ FDX COMPACT DIGITAL FORCE GAGE
CAPACITIES TO: 100 lbf / 50 kgf / 500 N



  • UNIQUE PISTOL GRIP HANDLE
  • TENSION & COMPRESSION
  • CAPACITIES TO: 100 lbf / 50 kgf / 500 N
  • SELECTABLE UNITS: lbf / kgf / N / ozf
  • RECHARGEABLE 50 HOUR BATTERY
  • PEAK FORCE HOLD & RECALL
  • NIST CALIBRATION CERTIFICATE
  • ACCURACY OF ± 0.3%

CONSTRUCTION

  • Firm pistol grip handle.
  • Fiberglass reinforced plastic housing.
  • 5 digit, 0.5'' LCD and 4 button keypad.
  • Displays: LO BAT, T, C and PEAK.
  • American standard threads.

OPERATION

  • Simple 4 button control and menu access.
  • Selectable units: lbf, kgf, N and ozf.
  • Selectable peak force sampling: 100 or 1000/sec.
  • Tension and compression peaks held in memory.

POWER

  • Rechargeable 50 hour NiMH battery.
  • Continuous operation with AC adapter/charger.
  • Auto-off conserves battery power.
  • "LO BAT" display warns of low battery power.

ACCESSORIES

  • NiMH battery, AC adapter/charger, hook and flat, case,manual and NIST Calibration Certificate.

ACCURACY

  • Accurate to ±0.3% of Full Scale ± 1 Least Significant Digit.

WEIGHT & DIMENSIONS

  • 0.5 lb [225g]. Shipping: 2lb [1kg].
  • 5'' [13 cm] H x 2 5/8'' [7 cm] W x 1 3/16'' [3 cm] D.
Optional hardware


The compact Force Ten ™ FDX is a low cost digital force gage, rich in useful features, for routine force testing. Advanced simplicity indicates the abundance of features added to the inexpensive FDX Digital Force Gage.

By sharing Wagner FDIX Force Gage software, a touch of sophistication is added to the FDX with selectable peak sampling, auto-off power conservation and ±0.3% accuracy.

The FDX is intended for hand-held force testing with a comfortable pistol grip handle operating on a rechargeable battery for portable use or continuous AC power for stationary use.

Selectable Peak Sampling Rate - The basic function of the FDX, measuring static and dynamic forces, is enhanced with selectable peak sampling rates. The FDX offers 100/second for slow dynamic or static testing and 1000/second for high speed break testing.

FORCE TEN ™ FDX DIGITAL FORCE GAGE
Model
Capacity / Graduation
Price
FDX 10
10 x .01 lbf
160 x . 2 ozf
5 x .005 kgf
50 x .05 N
$395
FDX 25
25 x .02 lbf
400 x . 5 ozf
10 x .01 kgf
100 x .1 N
$395
FDX 50
50 x .05 lbf
800 x 1 ozf
25 x .02 kgf
250 x .2 N
$395
FDX 100
100 x .1 lbf
1600 x 2 ozf
50 x .05 kgf
500 x .5 N
$395
Included: NiMH battery, AC adapter/charger, hook and flat, case,
manual and NIST Calibration Certificate.
OPTIONAL ACCESSORIES
FD/S-1
Steel Hook - Large (100 lbf)
$20*
FD/S-2
Flat Head - 5/8'' Diameter
$20*
FD/S-6
3'' Extension Rod
$20
FD/S-7
Hinged Hook - Large (100 lbf)
$45
FD/S-8
Hinged Cradle - Large (100 lbf)
$45
FD/RT
1 cm2 Flat Rubber Tip
$25
FDX/FP
3'' x 1 1/4'' Pressure Pad
$70
FDX/NIST
NIST Calibration Certificate
$135*
FDI/AC110
AC Adapter - 110 Vac+
$25*
FDI/AC220
AC Adapter - 220 Vac
$40*
*Included with FDX

fdx_150514_dd


  Prices and specifications are subject to change without notice. www.wagnerinstruments.com
